Water TechniX Eclipse AF150 Cartridge Filter – High-Capacity Filtration for Large Pools
The Water TechniX Eclipse AF150 Cartridge Filter delivers superior filtration at a cost-effective price, making it an excellent upgrade for large residential and commercial pools. Constructed from impact-resistant, UV-stabilised PVC and featuring a high-performance Trilobal filter element, it captures up to four times more dirt than standard filters. Designed for maximum efficiency and durability, this filter ensures crystal-clear water for pools up to 100,000 litres with minimal maintenance.
What are the key technical specifications of the Water TechniX Eclipse CF150?
This cartridge filter provides a 150 sq ft filtration area (model AF150) built with impact-resistant, UV‑stabilised PVC and a high-performance Trilobal filter element.
What is the maximum flow rate for this cartridge filter?
It is rated for a maximum flow rate of 556 liters per minute (LPM) under recommended operating conditions.
What pool volume is this filter designed to service?
The Eclipse CF150 is engineered to effectively filter pools with volumes up to 100,000 liters.
What materials and design features enhance its durability?
The filter’s construction includes an impact-resistant, UV‑stabilised PVC tank, reinforced Trilobal pleats for higher dirt capture, an ergonomic lid with handles, self‑sealing 50 mm barrel unions, and a stainless steel, oil‑filled pressure gauge.
What are the physical dimensions and configuration details of the unit?
The filter has an overall height of approximately 1107 mm (base to gauge) and an overall width of 225 mm, configured with three inlets and one outlet for flexible plumbing installation.
Key Features
- Heavy-duty, anti-corrosive PVC tank for long-term durability
- Trilobal filter material captures up to four times more debris for superior filtration
- Reinforced pleats prevent splitting and extend filter lifespan
- Three inlets and one outlet for flexible plumbing configurations
- Ergonomic tank lid with handles for easy removal and maintenance
- Screw-type air bleed valve for quick start-up and air release
- Stainless steel, oil-filled pressure gauge for accurate pressure monitoring
- Compatible with salt, mineral, chlorine, and magnesium pools
- Self-sealing 50mm barrel unions with silicone O-rings for secure connections
Specifications
- Model: AF150
- Maximum flow rate: 556 LPM
- Maximum pool size: 100,000 litres
- Overall height: 117cm ( base to gauge )
- Overall width: 225cm
- Warranty: 24 months on the tank, 12 months on the filter element
- Requires two reducing brushes (not included) for 40mm pipe applications
Built to Last
Engineered through five years of testing and refinements, the Water TechniX Eclipse AF150 Cartridge Filter is pressure-tested for durability and built with a reinforced filter core, making it one of the strongest filters on the market. With a 24-month tank warranty, it offers a long-lasting and reliable solution for hassle-free pool maintenance.
Cartridge or media (sand/glass/zeolite) filter that delivers crystal-clear water and strong flow. Pick the right filter size for your pool volume and pump rate; suits 40/50 mm plumbing with pressure gauge and multiport/backwash (media) or quick hose-off cleans (cartridge). Fine-micron clarity, straightforward install, and low-maintenance performance for salt, mineral, or chlorine pools.
Upgrade to the Water TechniX Eclipse AF150 Cartridge Filter today for high-efficiency filtration that keeps your pool water crystal clear all year round.
